Exterior length: 4630 mm.
Outside width: 2450 mm.
Internal length: 3750 mm.
Internal width: 2010 mm.
Interior area: 7.5 sqm.
Weight: 600 kg.
Height (bedding dispenser): 1650 mm.
Bedding dispenser volume: 400 liters.
Mat: Rubber 4,5 m with two layers of fabric.
Base: Wooden base covered with stainless steel.
Sides: Compact laminate 6mm.
Penning: Hot dip galvanized steel.
Indoors or outdoors, in new barns or in renovated barns.
The legs of the Groupbox can be adjusted to the existing concrete flooring.
Compressed air: 8 Bar (compressor not included, if installed outdoors the compressor must have dryer)
Control: PLC (transformer not included)
Electricity: 24 VDC (direct current).
Drive unit: Automotive brake chamber.
Compressed air: 8 Bar.
Compressed air consumption: 2 liters/movement.
How many calves can fit in one unit?
The surface for the calves is 7,5 sqm, normally 5 calves are kept in the Groupbox.
How does the floor move?
An easy PLC is programmed in the desired cleaning interval. The floor/rubber conveyor is slowly moved by mechanical movements generated by compressed air. Compressor is not included.
What delivery time do you have?
12 weeks. Each order will receive a specific delivery date.
Why should I choose Moving Floor?
Because it is the only calfbox on the market that automatically takes care of cleaning and bedding distribution. No manual labour can compete with Moving Floor. Average pay back is 2 years. The calves are clean, healthy and grow quicker.
How do I install Moving Floor?
Moving Floor is delivered flat packed and is mounted by you on spot. A mounting instruction will guide you through the steps. You need standard tools such as; wrench/drilling machine, wrenches 10-13-17, Allen keys.
How do I finance Moving Floor?
Moving Floor is considered a moveable property, it means leasing or installment is possible. Contact your bank or Moving Floor to learn more on flexible financing solutions.
